Security Rated Steel Door - SR1

Home / Our Doors / Steel Security Doors / Security Rated Steel Door - SR1
Securidor+ Blue Logo

The Securidor+ S1 security door range comprises of single and double security-rated steel door-sets that are specifically designed for use in locations that would benefit from enhanced protection. The typical applications for this range includes leisure facilities, schools and universities, housing association communal areas and general retail outlets.

Please note that these door-sets can only be supplied with outward opening leaves.

  • Secure for sure with Strongdor
  • Up to 3m high
  • Wide choice of hardware
Unique Range Features

Easy fit doors
1 year warranty
Steel door experts
Trustpilot rated Excellent

Download Tech Specs
Sbd logo
Made in Britain Colour
LPCBCertificationblack

Product Features

Height Icon
Height

Single - up to 3.1m
Double - up to 3.1m

Width Icon
Width

Single - up to 1.4m
Double - up to 2.8m

I5
Leaf Thickness

45mm deep leaf skin

Further information

Features
Drawings
Downloads

Frame
The welded frame is made from reinforced 1.5mm galvanised steel and a 38mm x 100mm single rebated profile. It is reinforced at the hinges, lock keeps and fixing points.

Leaf
Manufactured from 1.5mm galvanised attack face steel with 1.5mm inner face, the composite door leaf is 45mm thick with astragal lip to the closing edge. It weighs approximately 40kg per square metre.

Key Features
The range is certified to LPS1175 SR1, and fitted with a double hinge to top of door for additional strength. It also incorporates an anti leverage cover strip to closing edge of door leaf. The door-sets are also Secured by Design approved and are also available with solid over panels and hinged over panels which can be fixed, or removable.

Certification
Certified by the Loss Prevention Certification Board to LPS 1175 SR1 Issue 7 Cert/LPCB Ref. 1542a

Threshold
Aluminium and Type H.

Hardware
Choice of Exidor 301 Panic Actuator, Exidor 294A SD Panic Bolt available, an optional extra outside access device. Nemef Triple lockset, Zero Sashlock, Zero Nightlatch, IDC security Escutcheon. Flush Bolts or 12” Monkey Bolts to passive leaf. Keys and cylinders can be registered to eliminate the chance of key copying.

Finish
Wide choice of finishes available including powder coated finish from our range of RAL or BS colours.

Optional Extras
Door Viewer

Suitable Substrate
Structural timber or steelwork, blockwork or brickwork/ concrete blockwork.
Minimum Fixing Size - M6/No.12 .

Aluminium Threshold with Neoprene Seal

View File

Securidor Typical Leaf and Frame

View File
Strongdorlps1175explained22

LPS 1175 Explained

View File
Strongdor Lps1175 V Pas24

LPS 1175 vs PAS 24:2016 Key Differences
