Fire Rated Smoke Steel Door

Home / Our Doors / Steel Fire Doors / Fire Rated Smoke Steel Door
;
Firedor Logo Red

Certified Fire and Smoke Performance Up to E120Sa

Strongdor's Fire Rated Smoke Steel Door provides internal fire protection up to E120 and smoke control to E120Sa, tested to BS EN 1634-1 and 1634-3 standards. The door is suitable for internal use only and serves as a reliable safety barrier in escape and compartmentation areas.



Engineered for Stability and Durability

The door leaf is made of 1.2 mm 'Rustec steel', mechanically interlocked and internally bonded for superior strength and resistance to delamination. It includes an integrated astragal, a 44 mm thick door leaf, and a frame constructed from lightweight 1.5 mm steel, with an Adjust 2-Fit frame for on-site adjustment of up to 12 mm.



Clear Technical Credentials and Quick Supply

  • Height Capacity: up to 2.76 m (single and double).
  • Acoustic Rating: Up to 36 dB.
  • Includes 96 mm threshold (mandatory) and powder-coated finish in standard or extended RAL/BS colours.
  • Ships in 10–15 working days with factory-tested, easy-fit construction.



Specification Flexibility and Security

Customisable with PAS 24:2016 certification available, this door provides both fire & smoke protection, as well as enhanced security where needed. For comparably rated internal fire protection without smoke control, explore the Fire-Rated Internal Steel Door.

  • Fire-rated up to E120.
  • Available as PAS 24:2016.
  • Over 150 colours as standard.
  • Smoke-rated up to E120Sa.
Unique Range Features

World class steel doors.
Trustpilot rated Excellent.
1 year warranty.
Easy fit doors.
10-15 day lead time*

Download Tech Specs
ISO 9001
C e logo
Dhfjpg

Product Features

Height Icon
Height

Single - up to 2.76m.
Double - up to 2.76m.

Width Icon
Width

Single - up to 1.2m.
Double - up to 2.3m.

I5
Leaf Thickness

44mm deep leaf skin.

I6
Fire resistance

Fire-rated up to E120.

Strongdor Icons Acoustic
ACOUSTIC RATING

Up to 36dB rating.

NBS Specification

Further information

Features
Videos
Downloads

Frame

  • Manufactured from lightweight, high tensile 1.5 mm thick ‘Rustec’ steel.
  • Adjust 2-Fit side expander system that offers up to 12mm expansion to the structural opening.

Leaf

  • 44mm door leaf thickness incorporating an integrated astragal for added security.
  • Comprising of 1.2mm ‘Rustec’ steel sheets, the leaf skins are mechanically interlocked and internally bonded, proving greater stability and protection against de-lamination.

Threshold

  • Firedor Smoke is supplied with our 96mm threshold as standard.
  • Smoke doors cannot be supplied without a threshold.

Finish

  • Supplied inclusive of a powder coated finish in a standard colour.
  • Full range of RAL and BS colours available.

Door Ironmongery

  • Grade 13 stainless steel, twin bearing template, drilled butt hinges with integral high security dog bolts are fitted as standard with CE marking.
  • 316 Stainless steel hinges upgrade available.



Other hardware available includes:

  • Briton 5720 sashlock.
  • Stainless steel lever handles.
  • Fire-rated closers.
  • Flush bolts on the inactive leaf on doubles.
Strongdor Steel Door Single Install Thumbnail

Single Door Installation

This video contains detailed, step-by-step instructions for the safe installation of a Strongdor Steeldor single door-set. Please pay particular attention to the safety instructions.

Strongdor Double Door Install Thumbnail

Double Door Installation

This video contains detailed, step-by-step instructions for the safe installation of a Strongdor Steeldor double door-set. Please pay particular attention to the safety instructions.

Touching Up Paintwork

Touching up Paintwork

A demonstration of how to sue the touch up kit supplied with your steel door-set.

Strongdor extended colours thumbnail

Extended Colours & Coatings

View File
